Around 160 km, air stops behaving like a fluid.
Molecules travel farther between collisions than the spacecraft is wide. Continuum CFD no longer applies.
Very low Earth orbit
160 — 450 KM
Less atmosphere.
Still aerodynamics.
Free-molecular flow analysis and mission pre-design for very low Earth orbit. Panel method, gas–surface interaction models, results in seconds.
Every panel meets the flow on its own.
Atmospheric molecules arrive at about 7.7 km/s. Each surface element exchanges momentum with them independently.
Small forces. Mission-sized consequences.
Summed over every panel, those impacts become drag, lift and torque — the numbers behind orbit lifetime and attitude control.
Drag to turn the Earth
04 — Orbit
Pick an altitude. Watch the orbit.
Drag to turn the Earth. Lower orbits are faster and meet denser air — that is where aerodynamics starts to decide mission life.
- Orbital speed
- 7.73 km/s
- Period
- 90.5 min
- Orbits per day
- 15.9
Circular two-body orbit around a spherical Earth (μ = 398 600.4418 km³/s², R = 6 378.137 km). Spacecraft not to scale.
05 — Preview Demo and local engine
Try it on a CubeSat.
The demo shows three CubeSat presets at every orientation, precomputed. With an invite code, the full engine runs on your own computer: every setting, your own geometry, sweeps on all cores.
Drag coefficient Cᴅ—Aref = ½ total area
Drag force Fᴅ— µNAlong incident flow
Projected area A— m²Exposed to the flow
Aerodynamic torque M— µN·mAbout centre of mass
One spacecraft. 37 orientations.
Yaw −90° to +90° in 5° steps. All other parameters are held at the values captured when the sweep starts.
Behind the numbersModel assumptions & scientific references +
Satellite Aero’s own implementation of the Sentman free-molecular panel method, with Schamberg energy accommodation and Koppenwallner’s ½ correction. Each triangular panel contributes pressure and shear; forces and moments are summed about the selected centre of mass.
Panels hidden from the flow by other parts of the spacecraft are excluded, as are back-facing panels. Partial shading, secondary reflections, multiple gas species, atmospheric forecasting, orbital propagation, solar pressure and transitional flow are outside this preview’s scope. The specular option is a hyperthermal comparison. Refine your mesh and verify the free-molecular regime before using results in engineering studies.
By default the coefficients use Aref = half the total mesh area; the projected area can be selected instead. Forces use q = ½ρv². Coordinates are in metres; default flow is along −x, yaw rotates towards −y, and pitch towards −z.
Based on published theory: L. H. Sentman, Free molecule flow theory and its application to the determination of aerodynamic forces (1961); R. Schamberg, RAND Corporation (1959); G. Koppenwallner, Energy accommodation and momentum transfer modeling (2009). Results are exploratory and have not been independently validated.
06 — Access
Who it's for.
Students & educators
Learn free-molecular aerodynamics with every model explained and referenced. Free access for classrooms is planned.
Engineers & researchers
Check drag, torque and attitude sensitivity during pre-design, before committing to high-cost analysis tools.
Emerging space programmes
Check very low orbit concepts with a credible pre-design step, early in the mission.
DemoNo accountThree CubeSat presets at every orientation, precomputed. Sweeps and exports included.Now
Early accessFree · invite codeThe full engine on your own computer: every setting, your own OBJ/STL geometry, multi-core sweeps.Now
ClassroomSchools · studentsFree access for schools and university courses.Next
ProgrammesAgencies · companiesPre-design studies for mission teams and new space programmes.Later
07 — Research
From research to software.
IAC 2025 · SYDNEYAnalysis and Validation of Gas-Surface Interaction Models for VLEO Spacecraft Using ADBSat FrameworkT. Çebi, A. S. Durna — 32nd IAA Symposium on Small Satellite Missions, 76th International Astronautical Congress, pp. 195–206.DOI 10.52202/083084-0023 IAC 2026 · ANTALYADemocratizing VLEO Mission Design: Development of Open-Access Computational Tools for Emerging Space Nations and Commercial NewSpace Ventures77th International Astronautical Congress.IAC-26,E6,IP,24,x116316- NowDemo & invite-only full engine
- NextFree classroom programme for schools and universities
- LaterLive visualization of attitude and flow
- LaterPre-design studies for space programmes
